Advanced Home Safety Solutions SD-728 series optical smoke alarm and multisensors
SD-728 series is setting a new standard for reliability, performance and easy maintenance, using Advanced Photoelectric smoke Sensing Technology. These optical smoke alarms and multi-sensors are well suited to effectively respond to a wide spectrum of fires. The SD728-H seriesuses a smoke sensor in conjunction with a fixed temperature heat sensor to serve as combo smoke / heat alarm. The alarms are loaded with extra features and are available in a wide range of models. SD728 series is AC 220/230V or 9V battery powered. Designed for residential use.
Approvals
EN14604
The Range
|
SD-728 |
9V battery powered optical smoke detector for residential use |
|
SD-728-I |
9V battery powered optical smoke detector with interconnection function for residential use |
|
SD-728-H |
9V battery powered combo smoke & heat alarm for residential use |
|
SD-728-A2BI |
AC 220 / 230V powered with 9V battery backup and Interconnection function optical Smoke alarm for residential use |
Features and Benefits
- Photoelectric smoke alarm particularly effective detecting smoldering fires
- Combo smoke / heat alarm is used for detecting a wide range of fires
- Loud 85 dB alarm signal and flashing red LED light will indicate presence of smoke
- AC 220/230V and 9V battery powered (battery supplied)
- Manual test button helps to verify battery status and alarm operation
- Self- diagnostic sensor test
- Low battery warning
- Unique low-profile detector design easily blends with any decor
- Easy to install, move, and maintain
Specification
| Model | Power Source | Description |
| SD728 | 9V Battery | Optical smoke alarm |
| SD728-I | 9V Battery | Optical smoke alarm with interconnection function up to 38 additional units |
| SD728-A2B | AC 220/230V with 9V battery backup | Optical smoke alarm |
| SD728-A2BI | AC 220/230V with 9V battery backup | Optical smoke alarm with interconnection function up to 38 additional units |
| SD728-H | 9V Battery | Combo smoke / heat alarm |
| SD728-H-I | 9V Battery | Combo smoke / heat alarm with interconnection function up to 38 additional units |
| SD728-H-A2B | AC 220/230V with 9V battery backup | Combo smoke / heat alarm |
| SD728-H-A2BI | AC 220/230V with 9V battery backup | Combo smoke / heat alarm with interconnection function up to 38 additional units |
| Smoke Sensitivity | 0.10 - 0.150 dB/m |
| Power Supply | 9V battery; 100/110/120/220/230/240 Vac, 50 /60 Hz for AC versions |
| Battery Life | At least 18 months under normal conditions with Alkaline Battery |
| Low Battery Warning | Up to 30 days warning signal |
| Alarm Indicator | Continuously emitting red light |
| Alarm Sound Level | Exceeding 85 dB at 10 feet |
| Operating Temperature Range | 0°C to 50°C |
| Humidity | 10 to 85% RH, non-condensing |
